IP55
Over Current Protection
Over Temperature Protection
Current leakage protection
Over Voltage Protection
Short circuit protection
Voltage fluctuation protection
Lightning protection
This series of charging piles adopts a portable design, with a simple and elegant appearance, a stable frame, and easy use. The modular design facilitates long-term maintenance of the equipment. lt is an efficient DC charging equipment that provides electric energy for new energy vehicles.
Maximum Output Power | 20KW | |||
Net Weight | 30KG | |||
DC Output Voltage Range | 200~750VDC | |||
Dimension (H x W x D) | 782 x 472 x 314mm | |||
Max. Output Current | 60A | |||
Cable Length | 5m | |||
Charging Standard | CCS Type 2 | |||
Communications Interface | CAN, 485, 4G or Ethernet | |||
Efficiency | Above 95% | |||
Backstage Monitoring | OCPP1.6 JSON support | |||
Protection Class | IP55 | |||
Application Scenario | Floor-mounted/ Wall-mounted |
Whether you go for a long road trip or look for a handy EV charger to keep in your car for a stress-free ride, you’ll find the ideal solution here.
Connectivity-enabled seamless plug-and-charge experience; Remote scheduling and real-time charging status checking.
20kW Portable DC EV Charger
